MT3608 DC-DC 2A Boost Module 2V - 24V with Micro USB

MT3608 DC-DC 2A Boost Module Overview: The DC-DC Step-up module can take an Input of 2-24V with Output of 5-28V. Features a Micro-USB Input. Features/Operating Instructions: • Turn clockwise to boost Voltage, counter clockwise to reduce voltage. • The module supports MicroUSB input, a USB charger or mobile power supply can easily get to it 9V, 12V, 15V, 18V, 24V • Wide input and output voltage, high conversion efficiency. • Maximum output current: 2A (recommended for use within 1A) • Input voltage: 2 v ~ 24 v • Maximum output voltage:> 28 v (recommended for use within 26V) • Efficiency:> 93% • Size: 30mm * 17mm * 14mm (L * W * H) • This module is a step-up module, the output voltage is greater than the input voltage. • Peak current output current does not exceed 2A. • MT3608 1.2MHz boost converter IC • N.B If you experience that the output voltage cannot be adjusted, turn the potentiometer counter clockwise at least 10 times Package includes: • 1 X DC-DC 2A Boost Module 2V - 24V with Micro USB
